Swivel 50

Workers with back impairments can see behind equipment easier with a seat swivel.

Description

Workers with back impairments can see behind equipment easier with a seat swivel. Swivel seats will turn to the right or left so a worker can sit “sideways” and more easily see behind the tractor or equipment when the mirrors do not clearly display the equipment. Many hours are spent twisting around watching implements while operating tractors. This twisting is painful for people with back impairments and may not be possible due to stiffness or arthritis. The swivel seat bolts to the seat support pedestal and then the tractor seat bolts to the top of the swivel.

Click here for more swivel seat fabrication and installation ideas.

If you have any questions about whether this will fit your tractor, please contact us before ordering at 888-354-3289.



(Please note that this is designed for full sized tractors and not for lawn tractors. When you place your order we may need to contact you for more information to ensure the swivel will work for your equipment.)



Workers with common conditions such as these would benefit from a Seat Swivel.

Arthritis

Back Injury

Back Pain

Herniated Disc

Neck Injury

Ruptured Disc

Scoliosis

Slipped Disc



The KM Swivel 50 is made to fit the KM 235 Uni Pro Assembly, KM 600 Uni Pro Assembly and the KM 700 Uni Pro Assembly. It adds operator comfort, prevents neck and back muscle strain and makes entering and exiting the cab easier.

Features:

  • Steel construction with a powder coat finish
  • 1/16″ natural nylon plate
  • Swivels 360 degrees
  • Locks in one of five positions or allowed to swing freely
  • Handle stays in the front while you swivel
  • Easily mounts between the seat and suspension

Applications:
KM 235 Uni Pro Assembly, KM 600 Uni Pro Assembly or KM 700 Uni Pro Assembly

Allis Chalmers 7000, 7010, 7020, 7030, 7040, 7045, 7050, 7060, 7080, 7085, 8010, 8030, 8050, 8070, 6100, 6105, 6124, 6125, 6144, 6145, 6175, 6195, 6200, 6215, 9400, 9435, 9455, 9600, 9800, 9630, 9650, 9815, 9670, 9675, Case 730, 731, 740, 741, 770, 800, 801, 810, 830, 1290, 1294, 1390, 1490, 1690, 2090, 2290, 2390, 2590, 3294, 4490, 4690, 4890, 870, 970, 1070, 1170, 1175, 1270, 1370, 1570, 930, 1030

Case-IH 5120, 5130, 5140, 5220, 5230, 5240, 5250, 7110, 7120, 7130, 7140, 7150, 7210, 7220, 7230, 7240, 7255, 8910, 8920, 8930, 9110, 9130, 9150, 9170, 9180, 9190, 9210, 9230, 9240, 9250, 9260, 9270, 9280, 9310, 9330, 9370, 9380, 9390, 6000, 6010, 6100, 6110, 6200, 6210, 6300, 6310, 6400, 6410, 6500, 6510, 6700, 6710, 7000, 7010, 7100, 7110, 7200, 7210, 7300, 7310, 7400, 7410, 7500, 7510, 8630, 8640

White 4-175, 4-210, 4-225, 4-270

Oliver-White 100, 125, 1250, 1250 A, 1255, 1265, 1270, 1355, 1365, 1370, 145, 1450, 1465, 1470, 1500, 1550, 1555, 16 Field Boss, 160, 1600, 1650, 1655, 170, 1750, 1755, 1800, 1185, 1850, 1855, 1870, 1900, 195, 1950, 1950 T, 1855, 2-105, 2-110, 2-135, 2-150, 2-155, 2-180, 2-30, 2-32, 2-35, 2-44, 2-45, 2-50, 2-55, 2-60, 2-62, 2-65, 2-70, 2-75, 2-78, 2-85, 2-88, 2050, 21 Field Boss, 2150, 2155, 2250, 2255, 2270, 2655, 31 Field Boss, 37 Field Boss, 500, 550, 60 American, 600, 6045, 6065, 6085, 6090, 6105, 6124, 6125, 6144, 6145, 6175, 6195, 6215, 6410, 6510, 6710, 6810, 700, 750, 77, 770, 80 American, 8310, 8410, 8510, 8610, 8710, 88, 8810, 990, Super 44, Super 55, Super 66, Super 77, Super 88, Super 99
